Chiller Plant System
With primary & secondary pump and cooling tower
- Primary (chilled water) loop
- Secondary (chilled water) loop
- Condenser (water) loop
Speed
Chiller
- Status
- RUNNING
- Load
- 73 %
- Capacity
- 850 kW
- Power
- 141 kW
- COP
- 4.39
- kW/RT
- 0.80
Expansion Tank
- Pressure
- 181 kPa
- Level
- 69 %
Air Separator
- Pressure
- 212 kPa
- Temp.
- 27.9 °C
Cooling Tower
- CW In (Return)
- 32.1 °C
- CW Out (Supply)
- 30.0 °C
- ΔT
- 2.1 °C
- Wet Bulb
- 25.3 °C
- Fan Speed
- 55 %
- Fan Power
- 18 kW
Condenser Water Pump
- Status
- RUNNING
- Speed
- 60 %
- Flow
- 310 m³/h
- Head
- 28 m
- Power
- 15 kW
Primary Pump
(Chilled Water)
- Status
- RUNNING
- Speed
- 62 %
- Flow
- 145 m³/h
- Head (ΔP)
- 120 kPa
- Power
- 8.5 kW
Secondary Pump
(Chilled Water)
- Status
- RUNNING
- Speed
- 58 %
- Flow
- 138 m³/h
- Head (ΔP)
- 85 kPa
- Power
- 7.2 kW
ΔT (Chilled Water)
3.9 °C
(CHWR − CHWS)
Chilled Water Return (CHWR)
10.9 °C
Flow 145 m³/h
ΔP Primary Loop
120 kPa
ΔP Secondary Loop
85 kPa
Condenser Water Return (From Tower)
32.1 °C
Condenser Water Supply (To Chiller)
30.0 °C
To / From Building (Load)
619 kW
Flow 138 m³/h
Plant Summary
Total Cooling Capacity850 kW (242 RT)
Total Power Consumption189.7 kW
Current Cooling Load619 kW
Plant COP3.26
Plant Efficiency (kW/RT)1.08
Total Flow (CHW)145 m³/h (Primary)
138 m³/h (Secondary)
Plant Power Consumption
Total189.7 kW
- Chiller141.0 kW (74.3%)
- Primary Pump8.5 kW (4.5%)
- Secondary Pump7.2 kW (3.8%)
- C/W Pump15.0 kW (7.9%)
- Cooling Tower Fans18.0 kW (9.5%)
Alarm StatusCritical0Warning1Advisory0
Outdoor ConditionsDry Bulb 32.0 °CWet Bulb 25.3 °C
Date / Time--
